In a wireless world, spectrum is the new currency. Maximizing the value of every megahertz begins with your base station antennas. The right ones help you increase spectral efficiency, accelerate deployment, reduce overall costs, and even help save our planet. CommScope BSA are built to perform, simplify, and sustain.

Girls-Phone-500c281



Perform icon
 Perform

Our system-level approach, advanced engineering and relentless testing ensure maximum capacity and coverage while minimizing PIM and wind loading.

Simplify icon
Simplify

As RAN infrastructures grow more complex, our base station antennas help you simplify—supporting multiple bands, operators and functionalities with less equipment. Learn more

Sustain icon
Sustain

Our sustainable approach to antenna development helps you lower network energy use and consolidate network elements while minimizing waste and impact across the supply chain.

Products

of 655 results found
View:
Compare

Categories

Filters

10P-4L6M-D5 10P-4L6M-D5
10-port sector antenna, 4x 694–960 and 6x 1695–2690 MHz, 65° HPBW, 5x RET
10P-4L6M-D5
  • Product Type: Sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 3.0 m (10 ft)+
  • Width/Diameter: 458 – 498 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, mid band: 6
  • RF Connector Quantity, low band: 4
SpecificationsSpecs
10P-4L6M-D5
  • Product Type: Sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 3.0 m (10 ft)+
  • Width/Diameter: 458 – 498 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, mid band: 6
  • RF Connector Quantity, low band: 4
11653 11653
V-Bolt Mounting Kit for 3 in (76.2 mm) max OD round members. Set of two V-bolts clamp sets.
11653
  • Product Type: V-bolt mounting kit
SpecificationsSpecs
11653
  • Product Type: V-bolt mounting kit
2H-33A-R2 2H-33A-R2
4-port multibeam antenna, 4x 1695–2400 MHz, 2x 38° HPBW, 2x RET
2H-33A-R2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 306 – 353 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
SpecificationsSpecs
2H-33A-R2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 306 – 353 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
2HH-38A-R4-V2 2HH-38A-R4-V2
8-port multibeam antenna, 8x 1695–2200 MHz, 4x 38° HPBW, 4x RET
2HH-38A-R4-V2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
SpecificationsSpecs
2HH-38A-R4-V2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
2NN2HH-33B-R4 2NN2HH-33B-R4
16-port multibeam antenna, 8x 698–896 MHz, 2x 2-beam 33° HPBW and 8x 1695–2400 MHz, 2x 2-beam 33° HPBW, 4x RET
2NN2HH-33B-R4
  • Product Type: Sector antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 8
SpecificationsSpecs
2NN2HH-33B-R4
  • Product Type: Sector antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 8
2NN2HH-33C-R4 2NN2HH-33C-R4
16-port multibeam antenna, 8x 698–896 MHz, 2x 2-beam 33° HPBW and 8x 1695–2400 MHz, 2x 2-beam 33° HPBW, 4x RET
2NN2HH-33C-R4
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 8
SpecificationsSpecs
2NN2HH-33C-R4
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 8
2P-2L-C1 2P-2L-C1
2-port sector antenna, 2x 694–960 MHz, 65° HPBW, 1x RET
2P-2L-C1
  • Product Type: Sector antenna
  • Operating Frequency Band Range: 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 306 – 353 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 2
  • RF Connector Quantity, low band: 2
SpecificationsSpecs
2P-2L-C1
  • Product Type: Sector antenna
  • Operating Frequency Band Range: 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 306 – 353 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 2
  • RF Connector Quantity, low band: 2
2P-2L-C1-V2 2P-2L-C1-V2
2-port sector antenna, 2x 694–960MHz, 65°HPBW, 1x RET
2P-2L-C1-V2
  • Product Type: Sector antenna
  • Horizontal Beamwidth: 65°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 2
  • RF Connector Quantity, low band: 2
SpecificationsSpecs
2P-2L-C1-V2
  • Product Type: Sector antenna
  • Horizontal Beamwidth: 65°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 2
  • RF Connector Quantity, low band: 2
2RR2VV-33C-R4 2RR2VV-33C-R4
16-port multibeam antenna, 8x 694–960 MHz, 2x 2-beam 33° HPBW and 8x 1695–2690 MHz, 2x 2-beam 33° HPBW, 4x RET
2RR2VV-33C-R4
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, mid band: 8
  • RF Connector Quantity, low band: 8
SpecificationsSpecs
2RR2VV-33C-R4
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, mid band: 8
  • RF Connector Quantity, low band: 8
2SS-33A-R1 2SS-33A-R1
8-Port multibeam antenna ,8x 3100-4200 MHz , 4x 33° HPBW, 1x RET
2SS-33A-R1
  • Product Type: Multibeam antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, high band: 8
SpecificationsSpecs
2SS-33A-R1
  • Product Type: Multibeam antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, high band: 8
2UPX210B-T2 2UPX210B-T2
4-port multibeam antenna, 4x 694–896 MHz, 2x 37° HPBW, 2x RET with manual override.
2UPX210B-T2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, low band: 4
SpecificationsSpecs
2UPX210B-T2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, low band: 4
2UPX210B-T2-V2 2UPX210B-T2-V2
4-port multibeam antenna, 4x 694–896 MHz, 2x 37° HPBW, 2x RET
2UPX210B-T2-V2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, low band: 4
SpecificationsSpecs
2UPX210B-T2-V2
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 575 – 960 MHz
  • Horizontal Beamwidth: 33°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, low band: 4
